【LT8912B Single-Channel MIPI DSI Bridge to LVDS/HDMI,视频桥接方案介绍】

LT8912B通道MIPI DSI桥接至LVDS / HDMI

LT8912BSingle-Channel MIPI ® DSI Bridge to LVDS/HDMI

LT8912B 制造商Lontium

LT8912B 封装QFN64

LT8912B 最小包装2600/盘(可拆)

1.概述

LontiumLT8912 MIPI®DSI至LVDS和HDMI桥接器采用单通道MIPI®D-PHY接收器前端配置,每通道4个数据通道,每个数据通道1.5Gbps,最大输入带宽6Gbps。
LT8912T采用先进的CMOS工艺制造,采用0.5mm间距封装的12mm x 12mm LQFP和0.4mm间距封装的7.5mm x 7.5mm QFN封装。这些封装符合RoHS标准,额定工作温度范围为-40°C至+ 85°C。 2.特点

 •单端口MIPI®DSI接收器

 •单端口LVDS发送器

 •HDMI / MHL发射器

 •支持MIPI到LVDS桥的缩放器功能

 •单1.8V电源

3.APPLICATIONS •移动系统 •手机 •数码摄像机 •数码相机 •个人媒体播放器 •游戏

1. General Description

The LontiumLT8912B MIPI®DSI to LVDS and HDMI bridge features a single-channel MIPI®D-PHY receiver front-endconfiguration with 4 data lanes per channel operating at 1.5Gbps per data lane and a maximum input bandwidth of 6Gbps.

The LT8912B is fabricated in advanced CMOS process and implemented in both 12mm x 12mm LQFP at 0.5mm pitch package and 7.5mm x 7.5mm QFN at 0.4mm pitch package. These packages are RoHS compliant and specified to operate from −40°C to +85°C.

2. Features

• One-Port MIPI® DSI Receiver

• One-Port LVDS Transmitter

• HDMI Transmitter

• Support scaler function for MIPI to LVDS bridge

• Single 1.8V power supply

3.APPLICATIONS

• Mobile systems

• Cellular handsets

• Digital video cameras

• Digital still cameras

• Personal media players

• Gaming

   我公司可提供全套开发资料:规格书,电路图,DEMO,在线与原厂技术支持沟通推荐更适合客户的解决方案等等,能满足系统厂商不同的设计要求,欢迎广大客户来电咨询
