说明

利用YOLO训练好的挖掘机目标检测模型，通过Python flask进行部署，是一个比较直观快捷的模型展示方式。

flask项目结构及效果

通过前端上传所需识别图片，调用训练好的模型进行目标检测，将结果传回前端进行展示。

主程序代码

主程序代码如下：


config.py代码

```# -*- coding: utf-8 -*-class Args_config:    def __init__(self, device): self.batch_size = 1 self.cpu_threads = 1 self.device = device self.use_gpu = False if device.upper() == 'CPU' else True self.enable_mkldnn = False self.image_dir = None self.image_file = 'PaddleDetection/test_imgs/test1.jpg' self.model_dir = 'PaddleDetection/inference_model/ppyolo_r50vd_dcn_voc' self.output_dir = 'PaddleDetection/output' self.reid_batch_size = 50 self.reid_model_dir = None self.run_benchmark = False self.run_mode = 'fluid' self.save_images = False self.save_mot_txts = False self.threshold = 0.5 self.trt_calib_mode = False self.trt_max_shape = 1280 self.trt_min_shape = 1 self.trt_opt_shape = 640 self.use_dark = True # predict from video file or camera video stream self.camera_id = -1 self.video_file = None

项目链接

文件比较大，下载本项目请点击：
基于YOLO的挖掘机目标检测模型+flask模型前端展示
环境配置有疑问可以留言或私信交流。
